Enameled Rectangular(flat) Aluminum Wire

Diameter Range (mm): thickness: 0.80-5.60mm width: 2.00-16.00mm
Width/thickness ratio:1.4<w/t<8.0
Thermal Class: 130C, 155C, 180C, 200C, 220C
Standard: IEC, NEMA, GB, JIS
UL No:E338133
Package: Plastic spool, Wooden spool and according to customers requirements.



【Prev Products】 【Next Products】
E-mail Us PDF Download

ENAMELED RECTANGULAR(FLAT) ALUMINUM WIRE



Production Process






Step 1:Extruding&Drawing

Incoming quality control foreach material under strict standards.



Step2:Stretch the thread

Precise in size control to 0.001mm.



Step 3:Wash with pure water

Ultrasonic cleaning ensures no impurities when wires enamelling.

Step 4:Paint

Die method productions make wires excellent in surface enamelling control.

Step 5:ToastedUsing

ELANTAS insulation ensures wires excellent in adhesion.


Step 6:Spooling

24hours routing inspection:

the goods on production will be checked per 45mins through 24hours.




Application


Oil-filled transformers

General purpose motors

Potable generators

Communication apparatus

Electric devices

Magnet coils

High speed motors & generators

Solenoid coil

Motors used in refrigerator/ automobile

UPS power source







Packing：Plastic spool, Wooden spool and according to customers requirements.



Test of Main technical

Standard

IEC60317-0-3

MW36-A/ MW36-C

Test Item

Requirement

Test Result

Appearance

Uniform color smooth surface

Uniform color smooth surface

Insulation Thickness

0.06~0.11

0.12~0.17

Elongation

≥15%

30%

Bending

4A 4B

No film-cracking

Adhesion

Stretching 15% (≤1b)

Qualified

Heat shock

200C /220C / 240C 30min 3a

No film-cracking

Breakdown voltage

≥1000/ 2000V
